Casiotone CT-S500
Casiotone CT-S500
Specifications
Basic Information
Number of Keys
61
Touch Response
3 sensitivity levels, off
Sound Source
AiX
Maximum Polyphony
64
Number of Tones
800
Number of Rhythms/Patterns
243 User Rhythms: 50
Automatic Accompaniment
Yes
Built-in Songs
User Songs: 10
Demonstration Songs
1
Songs
Part Off: Left Hand, Right Hand, Both Hands
Recorder
[MIDI Recorder] 6 tracks, 5 songs Approximately 40,000 notes for each song
Speaker
[13cm x 6cm] x 2
Amplifiers
2.5W + 2.5W
Power Supply
AC Adaptor: AD-A12150LW (DC 12V) Batteries: AA-size alkaline batteries x 6 or AA-size rechargeable nickel metal hydride batteries* x 6 Battery Life: Approximately 3 hours continuous operation Actual continuous operation time may be shorter due to battery type, performance type, and usage environment. *Measured values while using eneloop batteries. eneloop is a trademark of Panasonic group.
Power Consumption
7.5W
Dimensions
930 x 258 x 91 mm (w/o music stand)
Weight
4.7kg (w/o batteries)
Color
Black
Included Accessories
Music Stand, AC Adaptor AD-A12150LW, Wireless MIDI & Audio Adaptor WU-BT10, Strap Lock
Key Features
Effects
Reverb: 24 (+Preset for each tone) Chorus: 12 (+ Preset for each tone) Delay: 15 (+ Preset for each tone) DSP Effect: 100 (+ Preset for each tone) Master EQ: 10 (+ User: 1) Surround
Layer/Split
Layer: 3 (Upper1/2, Lower1), Split: Yes
Octave Shift
-3 to +3 octaves
Transpose
-12 to +12 semitones
Tuning Control
A4 = 415.5 Hz to 440.0 Hz to 465.9 Hz
Scales
Equal temperament + 16 variations
Arpeggiator
150
Registration
64 setups (4 sets x 16 banks)
One Touch Presets
243
Auto Harmonize
12
Metronome
Beat Bell: Off, 1 to 9 (beats) Tempo Range: 20 to 255 Tap Tempo: Yes
LCD
Yes, Type: Full-dot, Back Light: Yes (white)
Pitch Bend Wheel
Yes
Knobs
3
Others
Dial
Yes
Volume Sync EQ
Yes
Others
・Sampling Function Input Method: Audio In / Media (WAV) Sampling Type / Time: Sampling Melody × 1 / Approx. 10 sec., Sampling Drum Set ×1 / Approx. 3 sec. Format: 44.1kHz, 16 bit, Stereo Loop Functionality
Input/Output Terminals
LINE OUT
2 (L/MONO, R): Standard jack
USB port
Type A, micro B
AUDIO IN
Stereo mini jack
PEDAL
PEDAL 1: Standard jack PEDAL 2 / EXPRESSION: Standard jack
PHONES/OUTPUT
PHONES: Stereo mini jack
Extended Functions
Connection to App
Supported App: CASIO MUSIC SPACE
Wireless Functionality
Bluetooth🄬 version 5.0 AUDIO Profile: A2DP, Supported Codec: SBC MIDI Profile: GATT (MIDI over Bluetooth🄬 Low Energy) (using supplied Wireless MIDI & Audio Adaptor WU-BT10)
MIDI
Yes (Using the USB port): GM level 1 compatible
